Sold out
ATEN KH1516AI-AX-U KVM switch Black
Regular price
$2,581.94
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
The KH1516Ai Cat 5 High-Density KVM over IP Switch offers 16 computer port configurations in a 1U-high housing for convenient rack mounting. They allow local and remote operators to monitor and access the entire enterprise data center over the Internet using a web-based browser.
The KH1516Ai features RJ-45 connectors and Cat 5e/6 cable to link to the computers and supports multiplatform. This ensures that high quality signals can travel over long distance- up to 50m without the need for KVM extenders. Utilizing KVM Adapter Cables for the final linkup, the KH1508Ai permits any combination of PCs, Macs, Sun computers, and serial devices to coexist on the installation.
In addition to TCP/IP connectivity, the KH1516Ai provides console ports for a locally attached USB or PS/2 console and a Laptop USB console (LUC) – allowing access and control from the data center as well as over the Net.
1x KH1516Ai Cat 5 High-Density KVM over IP Switch
1x Firmware Upgrade Cable
1x LIN6-04U1-M18G Laptop USB Console Cable USB-A to Micro USB-B
1x LIN2-481K-E12G Power Cord
1x Rack Mount Kit
1x Foot Pad Set (4 pcs.)
1x User Instructions
The KH1516Ai features RJ-45 connectors and Cat 5e/6 cable to link to the computers and supports multiplatform. This ensures that high quality signals can travel over long distance- up to 50m without the need for KVM extenders. Utilizing KVM Adapter Cables for the final linkup, the KH1508Ai permits any combination of PCs, Macs, Sun computers, and serial devices to coexist on the installation.
In addition to TCP/IP connectivity, the KH1516Ai provides console ports for a locally attached USB or PS/2 console and a Laptop USB console (LUC) – allowing access and control from the data center as well as over the Net.
1x KH1516Ai Cat 5 High-Density KVM over IP Switch
1x Firmware Upgrade Cable
1x LIN6-04U1-M18G Laptop USB Console Cable USB-A to Micro USB-B
1x LIN2-481K-E12G Power Cord
1x Rack Mount Kit
1x Foot Pad Set (4 pcs.)
1x User Instructions
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Keyboard port type: USB, PS/2
- Mouse port type: USB, PS/2
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 0 - 80%
- Maximum resolution: 1920 x 1200 pixels
- Video port type: VGA
- Number of computers controlled: 16
- LED indicators: Yes
- Built-in display: No
- Housing material: Metal
- Console ports: PS/2, USB A, VGA (D-Sub)
- HD type: WUXGA
- Console USB ports quantity: 2
- Hot keys: Yes
- Power consumption (typical): 8.9 W
- Power source: AC
- Manual: Yes
- Push button: Yes
- USB connector type: USB Type-A
Network
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 16
Operational conditions
- Storage relative humidity (H-H)
- 0 - 80%
- Storage temperature (T-T)
- -20 - 60 °C
Packaging content
- Quick installation guide
- Yes
Performance
- Scan interval
- 1,255 s
- Video bandwidth
- 60 Hz
Ports & interfaces
- PS/2 ports quantity
- 2
Power
- AC input frequency
- 50 - 60 Hz
- Input current
- 1 A
- Input voltage
- 100 - 240 V
Weight & dimensions
- Depth
- 16.36 cm
- Height
- 4.4 cm
- Weight
- 3.14 kg
- Width
- 43.72 cm
Manual
Materials
Housing material: Metal
