ATEN 8-Port 2-Bus CAT5e/6 KVM Over IP Switch, LUC (Laptop USB Console), with Audio & Virtual Media Support
Regular price
$3,989.56
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
Aten's new generation of KVM over IP switches – KN series allows local console access and remote over IP access for operators to monitor and access their entire data center over a network using a web-based browser. In addition, they offer out-of-band access with external modem support for BIOS-level troubleshooting when the network is down.
1x KN1108VA KVM over IP Switch
2x SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)
2x LIN2-418K-E12G Power Cords
1x LIN6-04U1-M18G Laptop USB Console Cable
1x Rack Mount Kit
1x Foot Pad Set (4 pcs.)
1x User Instructions
1x KN1108VA KVM over IP Switch
2x SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)
2x LIN2-418K-E12G Power Cords
1x LIN6-04U1-M18G Laptop USB Console Cable
1x Rack Mount Kit
1x Foot Pad Set (4 pcs.)
1x User Instructions
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Keyboard port type: USB, PS/2
- Mouse port type: USB, PS/2
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 0 - 80%
- Maximum resolution: 1920 x 1200 pixels
- Video port type: VGA
- Number of computers controlled: 8
- LED indicators: Yes
- Built-in display: No
- Housing material: Metal
- Console ports: USB A, Mini-DIN
- Rack mounting: No
- Console USB ports quantity: 2
- Master (outer) case height: 15.5 cm
- Master (outer) case length: 51.5 cm
- Master (outer) case width: 33.8 cm
- Products per master (outer) case: 1 pc(s)
- Hot keys: Yes
- Audio connections: Yes
Design
- Cascadable
- Yes
- Push button
- Yes
- Rack capacity
- 1U
- Wired remote switch
- Yes
Logistics data
- Harmonized System (HS) code
- 85176200
- Master (outer) case gross weight
- 5.58 kg
- Master (outer) case net weight
- 4.37 kg
Network
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 14
- Networking standards
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
- Security algorithms
- 802.1x RADIUS, FIPS 140-2, RSA, SSL/TLS
Operational conditions
- Storage temperature (T-T)
- -20 - 60 °C
Packaging content
- Cables included
- AC
- Manual
- Yes
- Rack mount kit
- Yes
Packaging data
- Package depth
- 51.5 cm
- Package height
- 15.5 cm
- Package weight
- 5.58 kg
- Package width
- 33.8 cm
Performance
- Firmware upgradeable
- Yes
- Number of users
- 64 user(s)
- Scan interval
- 1,255 s
Ports & interfaces
- Headphone outputs
- 1
- Number of microphone inputs
- 1
- PS/2 ports quantity
- 2
- Serial ports quantity
- 2
- Serial port type
- RJ-45
- USB 2.0 Type-A hub ports quantity
- 3
- USB connector type
- Mini-USB B, USB Type-A
- USB hub
- Yes
Power
- AC input frequency
- 50 / 60 Hz
- Input current
- 1 A
- Input voltage
- 100 - 240 V
- Power source
- AC
Sustainability
- Compliance certificates
- RoHS
System requirements
- Linux operating systems supported
- Yes
- Mac operating systems supported
- Yes
- Windows operating systems supported
- Yes
Weight & dimensions
- Depth
- 28.78 cm
- Height
- 4.4 cm
- Weight
- 4.37 kg
- Width
- 43.84 cm
Cables included: AC
Manual
Manual
Materials
Housing material: Metal
