D-Link 20km Long Range Wireless AC Bridge
Regular price
$435.75
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
The power to deliver connectivity over an even longer distance.
The DAP-3712 is the essential infrastructure wireless solution in providing high-speed connectivity to what was previously believed to be impossible-to-reach rural areas and challenging terrain.
High-Gain Directional Antenna
Fast, stable, and long-range wireless coverage for up to 20 km
TDMA Technology
High speeds and consistent coverage that filters out interference
IP66 Rated
Water-resistant and dust-tight housing boasts a longer product life
Point-to-Point and Point-to-Multipoint
Distribute connectivity to single or multiple locations wirelessly over long distances
8 kV Surge Protection
Your device and network are protected against unexpected surges, such as lightning
High-Speed Wi-Fi
Blazing speeds of up to 867 Mbps
Wi-Fi Security
128-bit personal and enterprise wireless encryption
PoE Ready
Power over Ethernet makes for an easier installation with a single cable
Designed for Wireless ISPs
Rapid and cost-effective Internet distribution to get customers connected
The power to withstand tough weather
The DAP-3712 is enclosed in an unobtrusive IP66-rated housing, protecting it from rain and dirt. With built-in 8 kV surge protection, the DAP-3712 has protection against unexpected surges (such as lightning strikes), enabling it to be deployed where it’s needed, even in harsh environments and tough conditions.
Bring connectivity to areas with limited or no access to fixed internet.
The DAP-3712 features state-of-the-art hardware, including powerful high-gain 23 dBi directional antennas that effortlessly extend the coverage of 5GHz wireless AC speeds of up to 867Mbps to distances of up to 20 km away.
Consistent coverage that filters out interference
The DAP-3712 supports TDMA technology, creating a schedule for the bridge's access point and the client. The sender and receiver are allocated a time slot for transmissions, eliminating hidden node data collisions, maximising airtime efficiency, significantly cutting down interference, and dramatically improving the transfer rate.
Simple installation with Power over Ethernet (PoE)
The DAP-3712 comes with a PoE injector included. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.
Free Next-Business-Day Service
Enjoy our free Next Business Day service, as standard with D-Link Business products, to replace faulty equipment quickly.
Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increases the lengths of warranties and further minimises downtime.
The DAP-3712 is the essential infrastructure wireless solution in providing high-speed connectivity to what was previously believed to be impossible-to-reach rural areas and challenging terrain.
High-Gain Directional Antenna
Fast, stable, and long-range wireless coverage for up to 20 km
TDMA Technology
High speeds and consistent coverage that filters out interference
IP66 Rated
Water-resistant and dust-tight housing boasts a longer product life
Point-to-Point and Point-to-Multipoint
Distribute connectivity to single or multiple locations wirelessly over long distances
8 kV Surge Protection
Your device and network are protected against unexpected surges, such as lightning
High-Speed Wi-Fi
Blazing speeds of up to 867 Mbps
Wi-Fi Security
128-bit personal and enterprise wireless encryption
PoE Ready
Power over Ethernet makes for an easier installation with a single cable
Designed for Wireless ISPs
Rapid and cost-effective Internet distribution to get customers connected
The power to withstand tough weather
The DAP-3712 is enclosed in an unobtrusive IP66-rated housing, protecting it from rain and dirt. With built-in 8 kV surge protection, the DAP-3712 has protection against unexpected surges (such as lightning strikes), enabling it to be deployed where it’s needed, even in harsh environments and tough conditions.
Bring connectivity to areas with limited or no access to fixed internet.
The DAP-3712 features state-of-the-art hardware, including powerful high-gain 23 dBi directional antennas that effortlessly extend the coverage of 5GHz wireless AC speeds of up to 867Mbps to distances of up to 20 km away.
Consistent coverage that filters out interference
The DAP-3712 supports TDMA technology, creating a schedule for the bridge's access point and the client. The sender and receiver are allocated a time slot for transmissions, eliminating hidden node data collisions, maximising airtime efficiency, significantly cutting down interference, and dramatically improving the transfer rate.
Simple installation with Power over Ethernet (PoE)
The DAP-3712 comes with a PoE injector included. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.
Free Next-Business-Day Service
Enjoy our free Next Business Day service, as standard with D-Link Business products, to replace faulty equipment quickly.
Our rapid-response technical support is designed to ensure businesses get the best support for their unique environment. Our extended warranty and enhanced service packages increases the lengths of warranties and further minimises downtime.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: White
- Antenna design: External
- Product type: Network bridge
- Wi-Fi: Yes
- Web-based management: Yes
- Storage relative humidity (H-H): 0 - 90%
- Reset button: Yes
- Operating temperature (T-T): -40 - 65 °C
- Mounting type: Pole
- Maximum transfer distance: 20000 m
- International Protection (IP) code: IP66
- Ethernet LAN interface type: Gigabit Ethernet
- Ethernet LAN (RJ-45) ports: Yes
- Ethernet LAN: Yes
- Operating relative humidity (H-H): 0 - 90%
- LED indicators: Signal strength
- Wi-Fi band: Single-band (5 GHz)
- Security algorithms: 128-bit AES
- Power source type: PoE
- Power over Ethernet (PoE): Yes
Antenna
- Antenna gain level (max)
- 23 dBi
- Antennas quantity
- 1
Certificates
- Certification
- CE, FCC
- Compliance certificates
- CE, Federal Communications Commission (FCC)
Data transmission
- Maximum data transfer rate
- 867 Mbit/s
Features
- Automatic Transmit Power Control (ATPC)
- Yes
- Material
- Acrylonitrile butadiene styrene (ABS)
- Surge protection
- Yes
General
- Video/mp4
- https://objects.icecat.biz/objects/89587272_70829274.mp4|https://objects.icecat.biz/objects/89587272_70829275.mp4
Logistics data
- Harmonized System (HS) code
- 85176990
Management features
- DHCP client
- Yes
Network
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN data rates
- 100,1000 Mbit/s
- Networking standards
- IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
- Static IP
- Yes
Operational conditions
- Storage temperature (T-T)
- -40 - 85 °C
Packaging data
- Quantity per pack
- 1 pc(s)
Ports & interfaces
- Connectivity technology
- Wired & Wireless
Power
- Power consumption (max)
- 15 W
- Power consumption (typical)
- 15 W
- Power over Ethernet (PoE) voltage
- 48 V
Security
- MAC address filtering
- Yes
Weight & dimensions
- Depth
- 24.1 cm
- Height
- 37.2 cm
- Weight
- 0.9 kg
- Width
- 37.2 cm
Wireless LAN features
- Channels quantity
- 2 channels
- Frequency band
- 5.180 - 5.825 GHz
- Signal strength
- 27 dBm
- WLAN data transfer rate (max)
- 867 Mbit/s
Materials
Material: Acrylonitrile butadiene styrene (ABS)
