Sold out
Lenovo 7ZT7A00547 network card Internal Fiber 10000 Mbit/s
Regular price
$219.87
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Green
- Connectivity technology: Wired
- Internal: Yes
- Host interface: PCI Express
- Interface: Fiber
- Networking standards: IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
- Harmonized System (HS) code: 85176990
- Ethernet LAN: Yes
- Linux operating systems supported: Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
- Compliance certificates: RoHS
- Ethernet LAN data rates: 10000 Mbit/s
- Server operating systems supported: Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
- Chipset: Intel® C624
- Jumbo frames support: Yes
- Cabling technology: 10GBase-T
- Jumbo frames: 9728
- VLAN tagging: Yes
- Certification: UL recognized to UL60950-1 2nd Edition\nFCC Rules, Part 15, Class A\nAustralian EMC Framework (RCM)\nJapan VCCI, Class A\nIndustry Canada, ICES-003, Class A\nEU (CE Mark)\nKorea KC-RRA, Class A
- Fiber ports quantity: 4
- Flow control support: Yes
Design
- Compatible products
- SR630\nSR650\nSR850\nSR860\nSR950
Network
- Maximum data transfer rate
- 10000 Mbit/s
- Quality of Service (QoS) support
- Yes
- Security algorithms
- SNMP
Other features
- Number of VLANs
- 4096
- PCI-SIG* SR-IOV Capable
- Yes
- Receive Side Scaling (RSS)
- Yes
System requirements
- Other operating systems supported
- VMware vSphere ESXi
Materials
