QNAP TS-H1277AXU-RP-R7-32G
Regular price
$10,247.83
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Hurry up, only 1 item left in stock.
Powered by AMD Ryzen™ 7000 Series processors based on the cutting-edge AMD socket AM5 platform, the ZFS-based TS-h1277AXU-RP storage and backup solution unleashes superb performance and enterprise-level potential. With a revolutionary multi-core processor, DDR5 RAM, M.2 PCIe Gen 5, and redundant power supplies, the TS-h1277AXU-RP delivers excellent performance, ultra-large bandwidth, and trusted reliability for performance-demanding Tier 2 storage, virtualization, 4K video editing, and PB-level storage applications.
Unmatched hardware design and high performance
The TS-h1277AXU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet diverse application requirements.
M.2 PCIe Gen 5 ultra-fast transfer speed
The TS-h1277AXU-RP comes with two M.2 2280 PCIe Gen 5 slots that allow for installing NVMe SSDs (including WD®, Micron®, Seagate®, Kingston®) to boost NAS performance. PCIe Gen 5 is backwards compatible with PCIe Gen 4 / PCIe Gen 3 for flexible SSD deployment.
Abundant I/O capabilities with PCIe Gen 4 expansion
The TS-h1277AXU-RP has three PCIe Gen 4 slots (twice the bandwidth of PCIe Gen 3) that allow for installing various expansion cards for expanding application potential.
Build an affordable Fibre Channel SAN environment
Common Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing QNAP dual-port 16Gb/32Gb Fibre Channel expansion cards in the TS-h1277AXU-RP, you have more budget-friendly options to add a NAS to a SAN environment. You can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.
Comprehensive backup and disaster recovery solution
The TS-h1277AXU-RP supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.
Multi-version snapshots mitigate ransomware threats
The TS-h1277AXU-RP supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.
Comprehensive security and privilege settings
The TS-h1277AXU-RP is loaded with flexible privilege settings and security measures. Besides IP blocking, QNAP Authenticator, HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.
Simplified privilege settings
The TS-h1277AXU-RP supports comprehensive access right settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACL to help IT staff efficiently manage user accounts and access rights for multiple NAS systems.
Superior security with QVPN
A virtual private network (VPN) allows secure access to network resources and services across public networks. QVPN supports creating a VPN client, using the TS-h1277AXU-RP as a VPN server, and WireGuard® VPN service with an easy-to-use interface for setting up a secure connection.
QuWAN SD-WAN
To facilitate digital transformation, multi-site expansion and remote working, QuWAN SD-WAN helps automatically mesh multi-site VPN. It features IPsec encryption and cloud-centric management, allowing secure multi-site network including QNAP NAS and VMware ESXi platforms.
Security Counselor
A security portal for the TS-h1277AXU-RP to check for weaknesses and offer recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.
Malware Remover
Regularly scan your TS-h1277AXU-RP using the latest malware definitions. If infected files are detected, they will be immediately removed to ensure NAS data security.
TeamViewer remote access
TeamViewer app enables remote management and connectivity to multiple NAS devices from Windows® PCs with an unparalleled level of safety, while increasing IT efficiency and end user productivity.
All-in-one virtual machine and container hosting solution
You can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows®, Linux®, UNIX®, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.
Container Station
Experience LXC and Docker® lightweight virtualization technologies, download apps from the built-in Docker Hub Registry®, import and export containers, and create abundant microservices.
ZFS-based QuTS hero operating system enhances NAS performance and data integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.
Flexibly switch to QTS operating system
The TS-h1277AXU-RP also supports QTS - QNAP’s standard NAS operating system – that provides great everyday performance, efficient memory utilization, and the advantage of Qtier auto-tiering. You can also migrate drives from your current QTS-based NAS to the TS-h1277AXU-RP.
Unmatched hardware design and high performance
The TS-h1277AXU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet diverse application requirements.
M.2 PCIe Gen 5 ultra-fast transfer speed
The TS-h1277AXU-RP comes with two M.2 2280 PCIe Gen 5 slots that allow for installing NVMe SSDs (including WD®, Micron®, Seagate®, Kingston®) to boost NAS performance. PCIe Gen 5 is backwards compatible with PCIe Gen 4 / PCIe Gen 3 for flexible SSD deployment.
Abundant I/O capabilities with PCIe Gen 4 expansion
The TS-h1277AXU-RP has three PCIe Gen 4 slots (twice the bandwidth of PCIe Gen 3) that allow for installing various expansion cards for expanding application potential.
Build an affordable Fibre Channel SAN environment
Common Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing QNAP dual-port 16Gb/32Gb Fibre Channel expansion cards in the TS-h1277AXU-RP, you have more budget-friendly options to add a NAS to a SAN environment. You can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.
Comprehensive backup and disaster recovery solution
The TS-h1277AXU-RP supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.
Multi-version snapshots mitigate ransomware threats
The TS-h1277AXU-RP supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.
Comprehensive security and privilege settings
The TS-h1277AXU-RP is loaded with flexible privilege settings and security measures. Besides IP blocking, QNAP Authenticator, HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.
Simplified privilege settings
The TS-h1277AXU-RP supports comprehensive access right settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACL to help IT staff efficiently manage user accounts and access rights for multiple NAS systems.
Superior security with QVPN
A virtual private network (VPN) allows secure access to network resources and services across public networks. QVPN supports creating a VPN client, using the TS-h1277AXU-RP as a VPN server, and WireGuard® VPN service with an easy-to-use interface for setting up a secure connection.
QuWAN SD-WAN
To facilitate digital transformation, multi-site expansion and remote working, QuWAN SD-WAN helps automatically mesh multi-site VPN. It features IPsec encryption and cloud-centric management, allowing secure multi-site network including QNAP NAS and VMware ESXi platforms.
Security Counselor
A security portal for the TS-h1277AXU-RP to check for weaknesses and offer recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.
Malware Remover
Regularly scan your TS-h1277AXU-RP using the latest malware definitions. If infected files are detected, they will be immediately removed to ensure NAS data security.
TeamViewer remote access
TeamViewer app enables remote management and connectivity to multiple NAS devices from Windows® PCs with an unparalleled level of safety, while increasing IT efficiency and end user productivity.
All-in-one virtual machine and container hosting solution
You can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows®, Linux®, UNIX®, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.
Container Station
Experience LXC and Docker® lightweight virtualization technologies, download apps from the built-in Docker Hub Registry®, import and export containers, and create abundant microservices.
ZFS-based QuTS hero operating system enhances NAS performance and data integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.
Flexibly switch to QTS operating system
The TS-h1277AXU-RP also supports QTS - QNAP’s standard NAS operating system – that provides great everyday performance, efficient memory utilization, and the advantage of Qtier auto-tiering. You can also migrate drives from your current QTS-based NAS to the TS-h1277AXU-RP.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Processor family: AMD Ryzen™ 7
- Internal memory: 32GB
- Operating system installed: QuTS hero
- Product colour: Black
- Warranty period: 5 years
- Chassis type: Rack (2U)
- Ethernet LAN: Yes
- Ethernet LAN (RJ-45) ports: 4
- Number of storage drives supported: 12
- Storage drives installed: No
- Supported storage drive types: HDD & SSD
- Type: NAS
- USB port: Yes
- Operating relative humidity (H-H): 5 - 95%
- Reset button: Yes
- Cooling type: Active
- Device class: Large Enterprise Business
- Ethernet LAN data rates: 10,100,1000,2500,5000,10000 Mbit/s
- On/off switch: Yes
- Power supply location: Built-in
Design
- Fan diameter
- 6 cm
- LED indicators
- HDD, LAN, Power, SSD, Status
- Number of fans
- 3 fan(s)
General
- Video/mp4
- https://www.youtube.com/embed/UqwDxjwtI9I?si=z__IP_QTfp7L-n36
Logistics data
- Harmonized System (HS) code
- 84714100
Memory
- ECC
- No
- Flash memory
- 4.88GB
- Internal memory type
- DDR5
- Maximum RAM supported
- 192GB
- Memory form factor
- UDIMM
- Memory slots
- 4
Network
- Copper ethernet cabling technology
- 10GBASE-T
- DHCP server
- Yes
- Dynamic DNS (DDNS)
- Yes
- Ethernet LAN data rate supported (max)
- 10000 Mbit/s
- iSCSI support
- Yes
- Jumbo frames support
- Yes
- Supported network protocols
- IPv4, IPv6
- Wake-on-LAN ready
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage relative humidity (H-H)
- 5 - 95%
- Storage temperature (T-T)
- -20 - 70 °C
Packaging content
- Cables included
- AC, LAN (RJ-45)
- Number of screws
- 84
- Package type
- Box
- Power cables quantity
- 2
Performance
- Access Control List (ACL)
- Yes
- Backup features
- Cloud, iSCSI LUN
- Backup function
- Yes
- Browser supported
- Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
- Built-in FTP server
- Yes
- Buzzer
- Yes
- Disk scan
- Yes
- Hot spare
- Yes
- Management protocols
- SNMP V2/V3
- Multilingual support
- Yes
- S.M.A.R.T. support
- Yes
- Security algorithms
- 256-bit AES, FIPS 140-2, HTTPS, TLS
- Share folder
- CIFS/SMB
- Snapshot
- Yes
- System log
- Yes
- Web-based management
- Yes
Ports & interfaces
- PCI Express x8 (Gen 4.x) slots
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
Power
- AC input frequency
- 50 - 60 Hz
- AC input voltage
- 100 - 240 V
- Fan voltage
- 12 V
- Number of power supply units
- 2
- Power consumption (typical)
- 367.65 W
- Power supply unit (PSU) capacity
- 500 W
- Redundant power supply (RPS) support
- Yes
Processor
- Bus type
- DMI3
- CPU configuration (max)
- 1
- Processor boost frequency
- 5.3 GHz
- Processor cores
- 8
- Processor manufacturer
- AMD
- Processor threads
- 16
Processor special features
- Embedded options available
- No
- Enhanced Intel SpeedStep Technology
- Yes
- Execute Disable Bit
- Yes
- Idle States
- Yes
- Intel 64
- Yes
- Intel Enhanced Halt State
- Yes
- Intel Secure Key Technology version
- 1.00
- Intel Trusted Execution Technology
- Yes
- Intel TSX-NI
- Yes
- Intel TSX-NI version
- 1.00
- Intel Virtualization Technology (VT-x)
- Yes
- Intel Virtualization Technology for Directed I/O (VT-d)
- Yes
- Intel VT-x with Extended Page Tables (EPT)
- Yes
Software
- Linux operating systems supported
- CentOS 7.0, Ubuntu 14.04
- Mac operating systems supported
- Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
- Operating system version
- h5.0.0
- Server operating systems supported
- Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
- Windows operating systems supported
- Windows 10, Windows 7, Windows 8
Storage
- Disk roaming
- Yes
- Hot-swap drive bays
- Yes
- Installed storage drive type
- No
- Online RAID expansion
- Yes
- Online RAID migration
- Yes
- RAID levels
- 0, 1, 5, 6, 10, 50, 60, JBOD
- RAID rebuild
- Yes
- RAID support
- Yes
- Storage drive sizes supported
- 2.5,3.5"
- Supported file systems
- FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4
- Supported storage drive interfaces
- Serial ATA II, Serial ATA III
- Total installed storage capacity
- 0TB
Weight & dimensions
- Depth
- 55 cm
- Height
- 8.86 cm
- Package depth
- 72.1 cm
- Package height
- 27.3 cm
- Package weight
- 17.6 kg
- Package width
- 56.7 cm
- Weight
- 13 kg
- Width
- 48.2 cm
Cables included: AC, LAN (RJ-45)
