StarTech.com Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber SMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Cisco Meraki MS225, MX400, MS250
Regular price
$577.98
Sale price
Regular price
Tax included.
Available in stock (16)
10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty
The MASFP10GBLR is a Cisco Meraki MA-SFP-10GB-LR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 10GbE connectivity over fiber cable, for 10GBASE-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
• Wavelength: 1310nm
• Maximum Data Transfer Rate: 10 Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• MTBF: 2,104,865 hours
• Power Consumption: Less than 1.2 Watts
• Digital Diagnostics Monitoring (DDM): Yes
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
The MASFP10GBLR is a Cisco Meraki MA-SFP-10GB-LR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 10GbE connectivity over fiber cable, for 10GBASE-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
• Wavelength: 1310nm
• Maximum Data Transfer Rate: 10 Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• MTBF: 2,104,865 hours
• Power Consumption: Less than 1.2 Watts
• Digital Diagnostics Monitoring (DDM): Yes
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Silver
- Interface type: SFP+
- SFP transceiver type: Fiber optic
- Maximum transfer distance: 10000 m
- Harmonized System (HS) code: 85369010
- Digital Diagnostics Monitoring (DDM): Yes
- Master (outer) case height: 20 cm
- Master (outer) case length: 30 cm
- Master (outer) case width: 25 cm
- Products per master (outer) case: 3 pc(s)
- Fiber optic connector: LC
- Hot-swap: Yes
- SFP transceiver standard: LR
- Mean time between failures (MTBF): 2104865 h
- Power consumption (typical): 1.2 W
- Wavelength: 1310 nm
- Compliance certificates: CE, RoHS
- Single-mode fiber (SMF) supported: Yes
- Duplex system: Full
- Networking standards: IEEE 802.3ae
Features
- Housing material
- Aluminium
Logistics data
- Country of origin
- China
Operational conditions
- Operating relative humidity (H-H)
- 5 - 95%
- Operating temperature (T-T)
- 0 - 70 °C
- Storage temperature (T-T)
- -40 - 85 °C
Packaging content
- Quantity per pack
- 1 pc(s)
Packaging data
- Package depth
- 11.4 cm
- Package height
- 3.3 cm
- Package weight
- 0.05 kg
- Package width
- 9.2 cm
Performance
- Maximum data transfer rate
- 10000 Mbit/s
Weight & dimensions
- Depth
- 5.84 cm
- Height
- 1.26 cm
- Weight
- 0.02 kg
- Width
- 1.39 cm
Materials
Housing material: Aluminium
