StarTech.com Single-Mode (SM) SC Fiber Media Converter for 10/100/1000 Networks, Standalone Gigabit Ethernet to SC Fiber Converter, 1310nm, 10km - TAA
Regular price
$187.06
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Hurry up, only 2 items left in stock.
Convert and extend a Gigabit Ethernet connection up to 10 km over single-mode SC fiber
This fiber media converter converts and extends a Gigabit Ethernet (1000 Mbps) network up to 10 km over single-mode fiber on 1000BASE-LX networks.
Extend your GbE network cost-effectively
The fiber media converter provides a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernet network infrastructures. The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation.
Reliable and scalable network connectivity
Supporting a maximum single-mode fiber cable distance of up to 10 km (6.2 mi.), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also delivers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network.
This fiber media converter converts and extends a Gigabit Ethernet (1000 Mbps) network up to 10 km over single-mode fiber on 1000BASE-LX networks.
Extend your GbE network cost-effectively
The fiber media converter provides a cost-effective way to transparently convert copper to fiber, or fiber to copper, for connecting remote sub-networks to larger fiber-optic networks. Providing both SC fiber and RJ45 Ethernet ports, it integrates easily into a wide range of Gigabit Ethernet network infrastructures. The RJ45 port supports triple-speed (10/100/1000 BASE-T) auto-negotiation.
Reliable and scalable network connectivity
Supporting a maximum single-mode fiber cable distance of up to 10 km (6.2 mi.), the media converter delivers a simple and reliable solution for connecting Gigabit Ethernet networks to remote locations, while ensuring solid network performance. It provides optimum network scalability for connecting two or more Ethernet network nodes, for instance, connecting two buildings on the same campus or facility. The media converter also delivers high-speed bandwidth to meet the increasing demands of large-scale workgroups that require expansion of a Gigabit Ethernet network.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Internal: No
- Fiber optic connector: SC
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 5 - 90%
- Ethernet LAN (RJ-45) ports: Yes
- Connectivity technology: Wired
- Auto MDI/MDI-X: Yes
- Fiber mode structure: Single-mode
- Fiber ports quantity: 1
- Duplex system: Full
- Compliance certificates: RoHS
- Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- LED indicators: Activity, Link, Power
- Maximum transfer distance: 10000 m
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Wavelength: 1310 nm
- Harmonized System (HS) code: 85176990
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet
- Certification: CE, FCC
General
- Video/mp4
- https://www.youtube.com/watch?v=uvD264te_FM
Logistics data
- Master (outer) case height
- 30.6 cm
- Master (outer) case length
- 58.2 cm
- Master (outer) case width
- 36.8 cm
- Products per master (outer) case
- 20 pc(s)
Network
- Converter input interface
- 10Base-T, 100Base-TX, 1000Base-T
- Converter output interface
- 100Base-LX
- Jumbo frames
- 9000
- Jumbo frames support
- Yes
- Maximum data transfer rate
- 1000 Mbit/s
- Store-and-forward
- Yes
Operational conditions
- Storage temperature (T-T)
- -10 - 70 °C
Packaging content
- AC adapter included
- Yes
- Quick installation guide
- Yes
Packaging data
- Package depth
- 22.6 cm
- Package height
- 7 cm
- Package weight
- 0.56 kg
- Package width
- 12 cm
Performance
- Mean time between failures (MTBF)
- 50000 h
- Wavelength-division multiplexing (WDM)
- No
Power
- External power adapter
- Yes
- Input current
- 0.5 A
- Input voltage
- 100 - 240 V
- Output current
- 2.6 A
- Output voltage
- 5 V
- Power plug type
- Type N
Weight & dimensions
- Depth
- 7 cm
- Height
- 2.6 cm
- Weight
- 0.2 kg
- Width
- 10.5 cm
AC adapter included
Materials
