ATEN 8-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
Regular price
$911.35
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
The CS1708A KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1708A can control up to 8 computers. As many as 31 additional switches can be daisy-chained to each other, so that up to 256 computers can all be controlled from a single keyboard-monitor-mouse console. Additionally, a front panel USB port is available for each computer to access any peripherals connected to it on a one-at-a-time basis.
1x KVM Switch with Standard Rack Mounting Kit
1x 2L-5202P PS/2 KVM Cable
1x 2L-5202U USB KVM Cable
1x LIN5-27X6-U21G Console Cable
1x Firmware Upgrade Cable
1x Foot Pad Set(4 PCS)
1x 0AD6-1605-24EG Power Adapter
1x User Instructions
1x KVM Switch with Standard Rack Mounting Kit
1x 2L-5202P PS/2 KVM Cable
1x 2L-5202U USB KVM Cable
1x LIN5-27X6-U21G Console Cable
1x Firmware Upgrade Cable
1x Foot Pad Set(4 PCS)
1x 0AD6-1605-24EG Power Adapter
1x User Instructions
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Keyboard port type: USB, PS/2
- Mouse port type: USB, PS/2
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 0 - 80%
- Maximum resolution: 2048 x 1536 pixels
- Video port type: VGA
- Number of computers controlled: 256
- LED indicators: Yes
- Built-in display: No
- Housing material: Metal
- Console ports: USB A, VGA (D-Sub)
- HD type: QXGA
- Rack mounting: Yes
- Console USB ports quantity: 1
- Master (outer) case height: 25.8 cm
- Master (outer) case length: 56.5 cm
- Master (outer) case width: 37.5 cm
- Products per master (outer) case: 3 pc(s)
- Hot keys: Yes
Design
- Push button
- Yes
- Rack capacity
- 1U
Display
- On Screen Display (OSD)
- Yes
Logistics data
- Harmonized System (HS) code
- 85176200
- Master (outer) case gross weight
- 12.2 kg
- Master (outer) case net weight
- 10.2 kg
Operational conditions
- Storage temperature (T-T)
- -20 - 60 °C
Packaging content
- Cables included
- KVM
Packaging data
- Package depth
- 54 cm
- Package height
- 23.3 cm
- Package weight
- 3.85 kg
- Package width
- 11.6 cm
Performance
- Daisy chain
- Yes
- DDC/DDC2 supported
- Yes
- DDC2B support
- Yes
- Firmware upgradeable
- Yes
- Scan interval
- 1,255 s
Ports & interfaces
- DC-in jack
- Yes
- USB connector type
- USB Type-A
Power
- Input voltage
- 5.3 V
- Power consumption (typical)
- 5 W
- Power source
- DC
Sustainability
- Compliance certificates
- RoHS
System requirements
- Linux operating systems supported
- Yes
- Mac operating systems supported
- Yes
- Windows operating systems supported
- Yes
Weight & dimensions
- Depth
- 15.99 cm
- Height
- 4.4 cm
- Weight
- 3.41 kg
- Width
- 43.72 cm
Cables included: KVM
Materials
Housing material: Metal
