StarTech.com MSA Uncoded SFP+ Module - 10GBASE-T - SFP to RJ45 Cat6/Cat5e - 10GE Gigabit Ethernet SFP+ - RJ-45 30m
Regular price
$423.92
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Hurry up, only 3 items left in stock.
10 Gbps | Copper | RJ45 | 30 m (98.4 ft) | Lifetime Warranty
The SFP10GBTST is an MSA compliant copper SFP transceiver that’s designed, programmed and tested to work with 10GBASE-T compatible switchess and routers. The SFP+ transceiver module supports a maximum distance of up to 30 m (98.4 ft.) and delivers dependable 10 GbE connectivity over copper cabling, which is a cost-effective alternative to fiber-optic cable setups.
Technical Specifications:
• Maximum Data Transfer Rate: 10 Gbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 30 m (98.4 ft.)
• MTBF: 4,598,430 hours DDM: No >
This SFP+ copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The SFP10GBTST is an MSA compliant copper SFP transceiver that’s designed, programmed and tested to work with 10GBASE-T compatible switchess and routers. The SFP+ transceiver module supports a maximum distance of up to 30 m (98.4 ft.) and delivers dependable 10 GbE connectivity over copper cabling, which is a cost-effective alternative to fiber-optic cable setups.
Technical Specifications:
• Maximum Data Transfer Rate: 10 Gbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 30 m (98.4 ft.)
• MTBF: 4,598,430 hours DDM: No >
This SFP+ copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Silver
- Interface type: SFP+
- SFP transceiver type: Copper
- Maximum transfer distance: 30 m
- Harmonized System (HS) code: 85369010
- Digital Diagnostics Monitoring (DDM): No
- Master (outer) case height: 29 cm
- Master (outer) case length: 63.8 cm
- Master (outer) case width: 34.2 cm
- Products per master (outer) case: 150 pc(s)
- Certification: CE, FCC
- Power consumption (typical): 2.3 W
- Compliance certificates: RoHS
- Brand compatibility: MSA Compliant
- Duplex system: Full
- Networking standards: IEEE 802.3an
- Operating temperature (T-T): 0 - 70 °C
- Operating relative humidity (H-H): 5 - 95%
- Housing material: Zinc steel
- Country of origin: China
Features
- Hot-Plug support
- Yes
Operational conditions
- Storage temperature (T-T)
- -40 - 85 °C
Packaging content
- Quantity per pack
- 1 pc(s)
Packaging data
- Package depth
- 7.6 cm
- Package height
- 3.4 cm
- Package weight
- 0.06 kg
- Package width
- 11.9 cm
Performance
- Auto MDI/MDI-X
- Yes
- Cabling technology
- 10GBASE-T
- Ethernet LAN (RJ-45) ports
- Yes
- Maximum data transfer rate
- 10000 Mbit/s
Weight & dimensions
- Depth
- 7 cm
- Height
- 1.26 cm
- Weight
- 0.03 kg
- Width
- 1.39 cm
Materials
Housing material: Zinc steel
