StarTech.com Thunderbolt 3 Dock - Dual 4K 60Hz Monitor TB3 Laptop Docking Station with DisplayPort, HDMI & 1080p VGA - 85W Power Delivery & Charging - 2x USB-A, Ethernet - Mac & Windows - TAA
Regular price
$165.59
Sale price
Regular price
Tax included.
Available in stock (39)
Laptop Dock | Mac & Windows® | HDMI | DisplayPort | VGA | 85W PD
Create a powerful and flexible workstation with this Thunderbolt™ 3 dock. With dedicated dual video output, you can connect your Thunderbolt 3 equipped MacBook Pro or Windows® laptop to two 4K monitors, through a single Thunderbolt 3 cable.
Easy Installation & Deployment
Simply connect the TB3 dock to your laptop with included TB3 cable and start working immediately. No time-consuming driver installations are required.
Speed & Flexibility with 3 Monitor Options
Great for editing 4K video or other Ultra HD tasks, this Thunderbolt 3 docking station supports 40Gbps speeds and 4K resolution at 60Hz on two monitors. Enjoy ultimate flexibility in setting up your workstation, with monitor options including DisplayPort (DP), HDMI and VGA.
The dock offers many dedicated dual-video options:
2x DisplayPort (4096 x 2160p @ 60Hz)
1x DisplayPort + 1 HDMI (4096 x 2160p @ 60Hz)
1x VGA (1920 x 1200p @ 60Hz) + 1x DisplayPort (4096 x 2160p @ 60Hz)
1x VGA (1920 x 1200p @ 60Hz) + 1x HDMI (4096 x 2160p @ 60Hz)
The Ports You Need Most
Harness the reliability and speed of a wired network connection with the Gigabit Ethernet port (supporting PXE Boot and Wake-on-LAN). Connect your USB devices with two USB 3.0 Type-A ports.
Power & Charge with 85W Power Delivery
Through a single 120W power adapter, the Thunderbolt 3 docking station simultaneously powers and charges your laptop and your attached peripherals while it's docked. It provides up to 85W of charging power through Power Delivery.
The StarTech.com Advantage
Create a powerful and flexible workstation with this Thunderbolt™ 3 dock. With dedicated dual video output, you can connect your Thunderbolt 3 equipped MacBook Pro or Windows® laptop to two 4K monitors, through a single Thunderbolt 3 cable.
Easy Installation & Deployment
Simply connect the TB3 dock to your laptop with included TB3 cable and start working immediately. No time-consuming driver installations are required.
Speed & Flexibility with 3 Monitor Options
Great for editing 4K video or other Ultra HD tasks, this Thunderbolt 3 docking station supports 40Gbps speeds and 4K resolution at 60Hz on two monitors. Enjoy ultimate flexibility in setting up your workstation, with monitor options including DisplayPort (DP), HDMI and VGA.
The dock offers many dedicated dual-video options:
2x DisplayPort (4096 x 2160p @ 60Hz)
1x DisplayPort + 1 HDMI (4096 x 2160p @ 60Hz)
1x VGA (1920 x 1200p @ 60Hz) + 1x DisplayPort (4096 x 2160p @ 60Hz)
1x VGA (1920 x 1200p @ 60Hz) + 1x HDMI (4096 x 2160p @ 60Hz)
The Ports You Need Most
Harness the reliability and speed of a wired network connection with the Gigabit Ethernet port (supporting PXE Boot and Wake-on-LAN). Connect your USB devices with two USB 3.0 Type-A ports.
Power & Charge with 85W Power Delivery
Through a single 120W power adapter, the Thunderbolt 3 docking station simultaneously powers and charges your laptop and your attached peripherals while it's docked. It provides up to 85W of charging power through Power Delivery.
The StarTech.com Advantage
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Grey
- Host interface: Thunderbolt 3
- Card reader integrated: No
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
- Connectivity technology: Wired
- Ethernet LAN: Yes
- HDMI ports quantity: 1
- Mac operating systems supported: Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura
- Ethernet LAN (RJ-45) ports: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Operating relative humidity (H-H): 20 - 80%
- Microphone in: No
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB Power Delivery (USB PD): Yes
- USB Power Delivery up to: 85 W
- Products per master (outer) case: 20 pc(s)
- Maximum digital resolution: 4096 x 2160 pixels
- Master (outer) case height: 28 cm
- Master (outer) case length: 67.6 cm
- Master (outer) case width: 39 cm
General
- Video/mp4
- https://www.youtube.com/watch?v=jYxZdU1gWH0&feature=youtu.be
Network
- 10G support
- No
- Auto MDI/MDI-X
- Yes
- Full duplex
- Yes
- Networking standards
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 70 °C
Other features
- Cable length
- 0.5 m
- Chipset
- Intel - Alpine Ridge JHL6540, Intel - WGI210AT, ASMedia - ASM1042A, Parade - PS176, Chrontel - CH7517
Packaging content
- AC adapter included
- Yes
- Cables included
- Thunderbolt
- Manual
- Yes
Packaging data
- Package depth
- 25.4 cm
- Package height
- 6.5 cm
- Package weight
- 1.3 kg
- Package width
- 18.7 cm
Performance
- Certification
- CE, FCC, REACH
- Data transfer rate
- 40 Gbit/s
- Housing material
- Aluminium
- UASP support
- Yes
Ports & interfaces
- DC-in jack
- Yes
- DisplayPorts quantity
- 2
- VGA (D-Sub) ports quantity
- 1
Power
- AC input voltage
- 100 - 240 V
- Compatible power plug types
- AU, JP, US
- Input current
- 1.8 A
- Output current
- 6.32 A
- Output voltage
- 19 V
- Power consumption (typical)
- 120 W
- Power plug type
- Type N
- Power source type
- AC
- Power supply type
- External
Software
- Mac compatibility
- Yes
Technical details
- Compliance certificates
- RoHS
Weight & dimensions
- Depth
- 19.6 cm
- Height
- 2.4 cm
- Weight
- 0.34 kg
- Width
- 5.86 cm
AC adapter included
Cables included: Thunderbolt
Manual
Cables included: Thunderbolt
Manual
Materials
Housing material: Aluminium
