TP-Link Omada 52-Port Gigabit Smart Switch with 32-Port PoE+
Regular price
$963.42
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Hurry up, only 1 item left in stock.
Power over Ethernet, Flexible Network Deployment
Easily Build a Whole 10G Multi-gigabit Network
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Easily Build a Whole 10G Multi-gigabit Network
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Switch type: Managed
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 10 - 90%
- Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3x
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE): Yes
- Switching capacity: 104 Gbit/s
- MAC address table: 16000 entries
- 10G support: No
- Storage relative humidity (H-H): 5 - 90%
- LED indicators: Yes
- Quality of Service (QoS) support: Yes
- Rack mounting: Yes
- Flow control support: Yes
- Jumbo frames support: Yes
- Switch layer: L2/L2+
- Forwarding rate: 77.37 Mpps
- Jumbo frames: 9000
Data transmission
- Static route
- Yes
Design
- Form factor
- 1U
Management features
- ARP inspection
- Yes
- Cloud-managed
- Yes
- Configuring Location Settings (CLI)
- Yes
- MIB support
- Yes
- System event log
- Yes
- Web-based management
- Yes
Network
- Active link detection
- Yes
- Auto MDI/MDI-X
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- IP routing
- Yes
- Link aggregation
- Yes
- Port mirroring
- Yes
- VLAN support
- Yes
Operational conditions
- Heat dissipation
- 1035.4 BTU/h
- Storage temperature (T-T)
- -40 - 70 °C
Ports & interfaces
- Power connector
- AC-in jack
- SFP module slots quantity
- 4
Power
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (max)
- 304.5 W
- Power source
- AC
- Power supply included
- Yes
Power over Ethernet (PoE)
- Power over Ethernet (PoE) power per port
- 30 W
- Power over Ethernet plus (PoE+) ports quantity
- 32
- Total Power over Ethernet (PoE) budget
- 230 W
Security
- Authentication type
- RADIUS
- DHCP features
- DHCP relay, DHCP server
- IGMP snooping
- Yes
- Loop protection
- Yes
- MAC address filtering
- Yes
- Security algorithms
- SNMP, SNMPv2, SNMPv3
- SSH/SSL support
- Yes
Weight & dimensions
- Depth
- 33 cm
- Height
- 4.4 cm
- Width
- 44 cm
Power supply included
Materials
