D-Link 48-port Gigabit Smart Managed Switch with 4 x 10G SFP+
Regular price
$1,185.36
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
Power & Value
The D-Link DGS-1250 Series Smart Managed Switches deliver real value as an Enterprise Access and Small-to-Medium Business (SMB) Access/Aggregation solution. They provide a range of physical interfaces (including a Console Port w/full CLI), multiple management interfaces, 11 Web languages, QoS enablement, and Advanced Layer-2 w/Lite Layer-3 features.
The DGS-1250 Series switches support 24 or 48 x 10/100/1000BASE-T ports, with each switch also supporting an additional 4 x 10G SFP+ ports for optical connections using multimode or single-mode SFP transceivers – enabling real network horsepower at a value price.
Easy Maintenance, Less Downtime
The DGS-1250 Series supports Dual Image and Dual Configuration functionality, as well as a Console Port, all of which make it easier to configure, troubleshoot, and make other changes without interfering with network operation, while full Command Line Interface (CLI) functionality enables remote configuration, without the need for the Internet. And if a network issue ever does occur, the supported Spanning Tree Protocols (STP/RSTP/MSTP) help keep things running without interruptions or downtime.
Automatic Configuration
The DGS-1250 Series supports Auto Voice VLAN and Surveillance Mode, which allow Voice and Video traffic to be automatically identified and handled differently from regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.
Extensive Management and Advanced Features
The DGS-1250 Series comes equipped with IGMP snooping, Port Mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers.
The series also supports advanced features such as Static Routing, which allows for communication between different user groups in different VLAN segments in a network. And, because the switches can manage internal routing, the network router can be assigned to handle external traffic.
Management Versatility
The DGS-1250 Series comes with the D-Link Network Assistant (DNA) utility so admins can remotely control their network to the port level. DNA allows customers to easily discover multiple D-Link Smart Managed Switches within the same L2 network segment and display them onscreen for instant access.
The D-Link DGS-1250 Series Smart Managed Switches deliver real value as an Enterprise Access and Small-to-Medium Business (SMB) Access/Aggregation solution. They provide a range of physical interfaces (including a Console Port w/full CLI), multiple management interfaces, 11 Web languages, QoS enablement, and Advanced Layer-2 w/Lite Layer-3 features.
The DGS-1250 Series switches support 24 or 48 x 10/100/1000BASE-T ports, with each switch also supporting an additional 4 x 10G SFP+ ports for optical connections using multimode or single-mode SFP transceivers – enabling real network horsepower at a value price.
Easy Maintenance, Less Downtime
The DGS-1250 Series supports Dual Image and Dual Configuration functionality, as well as a Console Port, all of which make it easier to configure, troubleshoot, and make other changes without interfering with network operation, while full Command Line Interface (CLI) functionality enables remote configuration, without the need for the Internet. And if a network issue ever does occur, the supported Spanning Tree Protocols (STP/RSTP/MSTP) help keep things running without interruptions or downtime.
Automatic Configuration
The DGS-1250 Series supports Auto Voice VLAN and Surveillance Mode, which allow Voice and Video traffic to be automatically identified and handled differently from regular network traffic. Auto Voice VLAN detects Voice over IP (VoIP) traffic and automatically segments it from the rest of the network, increasing security and allowing Quality of Service (QoS) to be applied.
Extensive Management and Advanced Features
The DGS-1250 Series comes equipped with IGMP snooping, Port Mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfers.
The series also supports advanced features such as Static Routing, which allows for communication between different user groups in different VLAN segments in a network. And, because the switches can manage internal routing, the network router can be assigned to handle external traffic.
Management Versatility
The DGS-1250 Series comes with the D-Link Network Assistant (DNA) utility so admins can remotely control their network to the port level. DNA allows customers to easily discover multiple D-Link Smart Managed Switches within the same L2 network segment and display them onscreen for instant access.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Internal memory: 2GB
- Product colour: Black
- Switch type: Managed
- Operating temperature (T-T): -5 - 50 °C
- Operating relative humidity (H-H): 0 - 95%
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE): No
- Switching capacity: 176 Gbit/s
- MAC address table: 32000 entries
- 10G support: Yes
- Storage relative humidity (H-H): 0 - 95%
- LED indicators: Activity, Link, Power, Speed
- Quality of Service (QoS) support: Yes
- Rack mounting: Yes
- Flow control support: Yes
- Jumbo frames support: Yes
- Switch layer: L3
- Forwarding rate: 130.95 Mpps
Certificates
- Certification
- CB, UL, BSMI, CCC
Data transmission
- Jumbo frames
- 12000
- Number of static routes
- 124
- Packet buffer memory
- 16MB
- Static route
- Yes
Design
- Electromagnetic compatibility
- CE A, VCCI A, FCC A, IC, BSMI
Logistics data
- Harmonized System (HS) code
- 85176990
Management features
- ARP inspection
- Yes
- Configuring Location Settings (CLI)
- Yes
- MIB support
- RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620,
- System event log
- Yes
- Web-based management
- Yes
Multicast features
- Multicast support
- Yes
Network
- Auto MDI/MDI-X
- Yes
- Broadcast storm control
- Yes
- Head-of-line (HOL) blocking
- Yes
- Link aggregation
- Yes
- Number of VLANs
- 4094
- Spanning tree protocol
- Yes
- Virtual LAN features
- Voice VLAN
- VLAN support
- Yes
Operational conditions
- Heat dissipation
- 174.592 BTU/h
- Storage temperature (T-T)
- -20 - 70 °C
Optical fiber
- Fiber ethernet cabling technology
- 100BASE-FX, 1000BASE-LHX, 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX, 1000BASE‑ZX
Packaging data
- Package depth
- 56.5 cm
- Package height
- 9.1 cm
- Package weight
- 4.28 kg
- Package width
- 35.1 cm
Performance
- Flash memory
- 64MB
- Mean time between failures (MTBF)
- 589984.72 h
- Memory type
- DDR3-SDRAM
- Noise level
- 50.7 dB
Ports & interfaces
- Console port
- RJ-45
- SFP+ module slots quantity
- 4
Power
- AC input frequency
- 50 - 60 Hz
- AC input voltage
- 100 - 240 V
- Power consumption (max)
- 51.2 W
- Power supply included
- Yes
Security
- Access Control List (ACL)
- Yes
- Access Control List (ACL) rules
- 768
- DHCP features
- DHCP client, DHCP server, DHCP snooping
- IGMP snooping
- Yes
- IP-MAC-Port binding
- Yes
- Loop protection
- Yes
- Queue scheduling algorithms
- Weighted Round Robin (WRR)
- Security algorithms
- EAP, LEAP, MD5, PEAP, SSH, SSL/TLS, TTLS
Technical details
- Master (outer) cases per pallet (air)
- 16 pc(s)
- Master (outer) cases per pallet (sea)
- 16 pc(s)
- Pallet gross length
- 110 cm
- Pallet gross weight (air)
- 382.7 kg
- Pallet gross weight (sea)
- 382.7 kg
- Pallet gross width
- 120 cm
- Pallet height (air)
- 167.1 cm
- Pallet height (sea)
- 167.1 cm
- Products per pallet (air)
- 80 pc(s)
- Products per pallet (sea)
- 80 pc(s)
- Products per shipping (inner) case
- 5 pc(s)
- Shipping (inner) case gross weight
- 22.8 kg
- Shipping (inner) case height
- 38.4 cm
- Shipping (inner) case length
- 58.5 cm
- Shipping (inner) case net weight
- 18.3 kg
- Shipping (inner) case width
- 47.8 cm
Weight & dimensions
- Depth
- 21 cm
- Height
- 4.4 cm
- Weight
- 3.01 kg
- Width
- 44 cm
