TP-Link 5-Port Gigabit Desktop PoE Switch with 4-Port
Regular price
$97.33
Sale price
Regular price
Tax included.
Shipping calculated at checkout.
Available in stock (199)
PoE Switches for Your Ultra Convenience
5-Port Gigabit Desktop Switch with 4-Port PoE
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 56W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.
5-Port Gigabit Desktop Switch with 4-Port PoE
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
Intelligent Power Management
When total power consumption excels 56W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.
Sturdy Metal Casing
Sturdy, compact metal casing and shielded RJ45 ports, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Key specifications
- Product colour: Black
- Switch type: Unmanaged
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 10 - 90%
- Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
- Basic switching RJ-45 Ethernet ports quantity: 5
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE): Yes
- Switching capacity: 10 Gbit/s
- MAC address table: 2000 entries
- 10G support: No
- Storage relative humidity (H-H): 5 - 90%
- LED indicators: Yes
- Quality of Service (QoS) support: Yes
- Rack mounting: No
- Flow control support: Yes
- Forwarding rate: 7.44 Mpps
- AC input voltage: 100 - 220 V
- IGMP snooping: Yes
- Power supply included: Yes
Certificates
- Certification
- FCC, CE, RoHS
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS
Data transmission
- Store-and-forward
- Yes
Design
- Stackable
- No
General
- Video/mp4
- https://objects.icecat.biz/objects/38057744_37764152.mp4
Logistics data
- Harmonized System (HS) code
- 85176990
Network
- Auto-negotiation
- Yes
- Auto MDI/MDI-X
- Yes
- Cable types supported
- Cat3, Cat4, Cat5, Cat5e, Cat6
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX, 1000BASE-T
- MAC address auto-aging supported
- Yes
- MAC address auto-learning supported
- Yes
- VLAN support
- Yes
Operational conditions
- Heat dissipation
- 219.87 BTU/h
- Storage temperature (T-T)
- -40 - 70 °C
Packaging content
- Cables included
- AC
- Manual
- Yes
- Quick start guide
- Yes
- User guide
- Yes
Packaging data
- AC adapter included
- Yes
- Package depth
- 19.6 cm
- Package height
- 12.1 cm
- Package type
- Box
- Package weight
- 0.76 kg
- Package width
- 13.1 cm
Performance
- Fanless
- Yes
- Maximum cable length
- 100 m
Ports & interfaces
- Gigabit Ethernet (copper) ports quantity
- 5
Power
- AC input frequency
- 50 Hz
- DC input voltage
- 48 V
- Input current
- 1.25 A
- Power consumption (max)
- 64.44 W
- Power source
- DC/PoE
Power over Ethernet (PoE)
- Power over Ethernet (PoE) ports quantity
- 4
- Total Power over Ethernet (PoE) budget
- 56 W
Sustainability
- Sustainability compliance
- Yes
Weight & dimensions
- Depth
- 9.8 cm
- Height
- 2.5 cm
- Width
- 9.98 cm
Cables included: AC
Manual
Quick start guide
AC adapter included
Power supply included
Manual
Quick start guide
AC adapter included
Power supply included
Materials
